The Summit 2196 ANSI Pumps are open impeller, centrifugal model with end suction/ top discharge. The Summit 2196 ANSI Pumps are designed for handling mild industrial corrosives. Capacities to 6000 gpm – Heads to 730 feet – Temperatures to 700 degrees F Features: Back Pull Out Design; External Impeller Adjustment; Maximum Interchangeability; Standard Bronze Inpro® Labyrinth Seals; Heavy Duty Shaft & Bearings; Rigid Frame Foot; Fully Open Impeller; Extra Large Oil Sump.
Capacity: up to 6000 GPM / 730 Ft
Features:
Rear Pull-Out Design
Efficient Interchangeable Parts
Capacities to 6000 GPM
Heads to 730 feet
Temperatures to 700 deg F
Fully Open Impeller
Extra Large Oil Sump
Rigid Frame Foot
Applications:
Water, Chemical, Oil, Pulp, and Paper, General Purpose Pump
Features:
Utilizes your existing 2196 power end and ANSI bolt pattern
Handles fibrous and shear sensitive materials
Minimizes degradation of solids
Available in 5 different sizes and a variety of materials
Applications:
Paper & Pulp, Cleaners, Manure Transfer, Waste Water, Fruit Pulp
Capacity: up to 225 GPM/ 900 Ft
Features
Low Flow High Head Applications
Radial Vane Impeller
Balance Holes on Impeller
Interchangeability with Existing ANSI Pump
Rigid Frame Foot
Applications:
Additive Chemicals, Batch/Continuous Chemical Reactors, Chemical Dryers, Chemical Processes, Condensate Service, Evaporators, Petro Chemical Service, Shower Services
PUMP CURVES
